SKU: SKU: SUBFA20BP320
Profile: BP320.
Application: Race.
Unit Type: Blank.
Note: These camshafts DO NOT FITthe FA20DIT engine! We can supply these, but are custom steel billet versions.
Also suits Toyota GT86.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 7 kg |
|---|---|
| Application | Race |
| Duration Inlet | 304° |
| Duration Exhaust | 292° |
| Valve Inlet Lift | .512" 13.00mm |
| Valve Exhaust Lift | .494" 12.55mm |
| Timing Inlet | 42 - 82 |
| Timing Exhaust | 76 - 36 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 110° |
| TDC Inlet Lift | .092" 2.34mm |
| TDC Exhaust Lift | .069" 1.74mm |
| Valve Inlet Clearance | .005" .13mm |
| Valve Exhaust Clearance | .007" .18mm |
