SKU: SKU: SUBFA20BP300
Profile: BP300.
Application: Rally.
Unit Type: Blank.
Note: These camshafts DO NOT FITthe FA20DIT engine! We can supply these, but are custom steel billet versions.
Also suits Toyota GT86.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 7 kg |
|---|---|
| Application | Rally |
| Duration Inlet | 284° |
| Duration Exhaust | 274° |
| Valve Inlet Lift | .492" 12.50mm |
| Valve Exhaust Lift | .472" 11.99mm |
| Timing Inlet | 32 - 72 |
| Timing Exhaust | 67 - 27 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 110° |
| TDC Inlet Lift | .072" 1.83mm |
| TDC Exhaust Lift | .050" 1.27mm |
| Valve Inlet Clearance | .005" .13mm |
| Valve Exhaust Clearance | .007" .18mm |
