SKU: SKU: SUBFA20BP285
Profile: BP285
Application: Ultimate Road.
Unit Type: Blank.
Note: These camshafts DO NOT FITthe FA20DIT engine! We can supply these, but are custom steel billet versions.
Also suits Toyota GT86.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 7 kg |
|---|---|
| Application | Ultimate Road |
| Duration Inlet | 272° |
| Duration Exhaust | 266° |
| Valve Inlet Lift | .472" 11.99mm |
| Valve Exhaust Lift | .445" 11.30mm |
| Timing Inlet | 26 - 66 |
| Timing Exhaust | 63 - 23 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 110° |
| TDC Inlet Lift | .050" 1.27mm |
| TDC Exhaust Lift | .037" 0.94mm |
| Valve Inlet Clearance | .005" .13mm |
| Valve Exhaust Clearance | .007" .18mm |
