SKU: SKU: SAX16BP300MB
Profile: BP300M.
Application: Rally.
Unit Type: Blank.
Note: Designed to be used in engines utilising Mechanical followers.
Note:Not suitable for standard O.E springs, Piper VDSVTS spring kit must be used.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 3 kg |
|---|---|
| Application | Rally |
| Power Band | 3600-8000 |
| Duration Inlet | 284° |
| Duration Exhaust | 284° |
| Valve Inlet Lift | .450" 11.44mm |
| Valve Exhaust Lift | .448" 11.39mm |
| Timing Inlet | 36 - 68 |
| Timing Exhaust | 68 - 36 |
| Full Inlet Lift | 106° |
| Full Exhaust Lift | 106° |
| TDC Inlet Lift | .112" 2.84mm |
| TDC Exhaust Lift | .110" 2.79mm |
| Valve Inlet Clearance | .010" .25mm |
| Valve Exhaust Clearance | .012" .30mm |
