SKU: SKU: SAX16BP320MB
Profile: BP320M.
Application: Race.
Unit Type: Blank.
Note: Designed to be used in engines utilising Oversized Mechanical followers.
Note:Piper FOLVTSM31 oversize followers must be used.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 3 kg |
|---|---|
| Application | Race |
| Power Band | 4200-8500 |
| Duration Inlet | 292° |
| Duration Exhaust | 292° |
| Valve Inlet Lift | .481" 12.21mm |
| Valve Exhaust Lift | .479" 12.16mm |
| Timing Inlet | 42 - 70 |
| Timing Exhaust | 70 - 42 |
| Full Inlet Lift | 104° |
| Full Exhaust Lift | 104° |
| TDC Inlet Lift | .169" 4.29mm |
| TDC Exhaust Lift | .167" 4.24mm |
| Valve Inlet Clearance | .010" .25mm |
| Valve Exhaust Clearance | .012" .30mm |
