SKU: SKU: SAX16BP300HB
Profile: BP300H.
Application: Rally.
Unit Type: Blank.
Note: Designed to be used in engines utilising hydraulic followers.
Note:Not suitable for standard O.E springs, You must use VSSVTSK with these camshafts.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 3 kg |
|---|---|
| Application | Rally |
| Power Band | 3500-8000 |
| Duration Inlet | 274° |
| Duration Exhaust | 274° |
| Valve Inlet Lift | .430" 10.93mm |
| Valve Exhaust Lift | .430" 10.93mm |
| Timing Inlet | 33 - 61 |
| Timing Exhaust | 63 - 31 |
| Full Inlet Lift | 104° |
| Full Exhaust Lift | 106° |
| TDC Inlet Lift | .107" 2.73mm |
| TDC Exhaust Lift | .096" 2.43mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
