SKU: SKU: SAX16BP285HB
Profile: BP285H.
Application: Ultimate Road.
Unit Type: Blank.
Note: Not recommended for standard injection engines.
Note: Designed to be used in engines utilising hydraulic followers. You must use VSSVTSK with these camshafts.
Note:When used in conjunction with throttle bodies, flowed head, manifold this profile achieves over 180 bhp!
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 3 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 3000-7500 |
| Power Increase | 20BHP |
| Duration Inlet | 264° |
| Duration Exhaust | 260° |
| Valve Inlet Lift | .400" 10.16mm |
| Valve Exhaust Lift | .380" 9.65mm |
| Timing Inlet | 22 - 62 |
| Timing Exhaust | 64 - 16 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 114° |
| TDC Inlet Lift | .058" 1.47mm |
| TDC Exhaust Lift | .016" 0.40mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
