SKU: SKU: JAGV6BP285B
Profile: BP285.
Application: Ultimate Road.
Unit Type: Blank.
Note: Only available for S-Type engine.
Note: Not suitable for VVT engines.
Note: Use with FOLJV6 followers. (Shim under bucket type).
Download:-
Right click link and select 'Save link as' to download.
Click link to open in a new tab.
| Weight | 10 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 2000-7000 |
| Duration Inlet | 280° |
| Duration Exhaust | 272° |
| Valve Inlet Lift | .444" 11.28mm |
| Valve Exhaust Lift | .428" 10.87mm |
| Timing Inlet | 36 - 64 |
| Timing Exhaust | 62 - 30 |
| Full Inlet Lift | 104° |
| Full Exhaust Lift | 106° |
| TDC Inlet Lift | .110" 2.80mm |
| TDC Exhaust Lift | .080" 2.04mm |
| Valve Inlet Clearance | .010" .25mm |
| Valve Exhaust Clearance | .012" .30mm |
