SKU: SKU: JAGV6BP270B
Profile: BP270.
Application: Fast Road.
Unit Type: Blank.
Note: Only available for S-Type engine.
Note: Not suitable for VVT engines.
Note: Use with FOLJV6 followers. (Shim under bucket type).
Download:-
Right click link and select 'Save link as' to download.
Click link to open in a new tab.
| Weight | 10 kg |
|---|---|
| Application | Fast Road |
| Power Band | 1500-6000 |
| Power Increase | 20BHP |
| Duration Inlet | 272° |
| Duration Exhaust | 264° |
| Valve Inlet Lift | .376" 9.55mm |
| Valve Exhaust Lift | .374" 9.50mm |
| Timing Inlet | 30 - 62 |
| Timing Exhaust | 60 - 24 |
| Full Inlet Lift | 106° |
| Full Exhaust Lift | 108° |
| TDC Inlet Lift | .072" 1.82mm |
| TDC Exhaust Lift | .049" 1.26mm |
| Valve Inlet Clearance | .010" .25mm |
| Valve Exhaust Clearance | .012" .30mm |
