SKU: SKU: CVHBP300MB
Profile: BP300M
Application: Rally.
Unit Type: Blank.
Designed to run with mechanical followers. Torque and power in abundance.
Note: Standard springs coil bind, Piper VDSCVH2 springs must be used.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 6 kg |
|---|---|
| Application | Rally |
| Power Band | 2800-7500 |
| Duration Inlet | 302° |
| Duration Exhaust | 302° |
| Valve Inlet Lift | .506" 12.84mm |
| Valve Exhaust Lift | .504" 12.79mm |
| Timing Inlet | 45 - 77 |
| Timing Exhaust | 77 - 45 |
| Full Inlet Lift | 106° |
| TDC Inlet Lift | .165" 4.19mm |
| TDC Exhaust Lift | .163" 4.14mm |
| Valve Inlet Clearance | .010" .25mm |
| Valve Exhaust Clearance | .012" .30mm |
