SKU: SKU: CVHBP320MB
Profile: BP320M.
Application: Race.
Unit Type: Blank.
Designed to run with Mechanical followers. When raw power is required, this is the profile to fit.
Note: Standard springs coil bind, Piper VDSCVH2 springs must be used.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 6 kg |
|---|---|
| Application | Race |
| Power Band | 4000-8000 |
| Duration Inlet | 352° |
| Duration Exhaust | 352° |
| Valve Inlet Lift | .458" 11.63mm |
| Valve Exhaust Lift | .458" 11.63mm |
| Timing Inlet | 73 - 99 |
| Timing Exhaust | 99 - 73 |
| Full Inlet Lift | 103° |
| TDC Inlet Lift | .180" 4.57mm |
| TDC Exhaust Lift | .178" 4.52mm |
| Valve Inlet Clearance | .014" .35mm |
| Valve Exhaust Clearance | .016" .40mm |
