SKU: SKU: CVHBP285B
Profile: BP285.
Application: Ultimate Road Injection.
Unit Type: Blank.
Designed for use in injection engines only. Excellent power and torque coupled with smooth idle.
Note:Standard springs coil bind, Piper VSSCVH springs must be used.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 6 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 1500-6600 |
| Power Increase | 12BHP |
| Duration Inlet | 276° |
| Duration Exhaust | 276° |
| Valve Inlet Lift | .440" 11.17mm |
| Valve Exhaust Lift | .440" 11.17mm |
| Timing Inlet | 30 - 66 |
| Timing Exhaust | 66 - 30 |
| Full Inlet Lift | 108° |
| TDC Inlet Lift | .080" 2.03mm |
| TDC Exhaust Lift | .080" 2.03mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
