SKU: SKU: CVHBP285CB
Profile: BP285C.
Application: Ultimate Road 1600 Carburettor.
Unit Type: Blank.
Massive mid range and top end power gains.
Note:Standard springs coil bind, Piper VSSCVH springs must be used.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 6 kg |
|---|---|
| Application | Ultimate Road Carburettor |
| Power Band | 2000-7000+ |
| Power Increase | 15BHP |
| Duration Inlet | 280° |
| Duration Exhaust | 280° |
| Valve Inlet Lift | .495" 12.57mm |
| Valve Exhaust Lift | .495" 12.57mm |
| Timing Inlet | 34 - 66 |
| Timing Exhaust | 66 - 34 |
| Full Inlet Lift | 106° |
| TDC Inlet Lift | .096" 2.43mm |
| TDC Exhaust Lift | .096" 2.43mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
