SKU: SKU: CVHBP270B
Profile: BP270.
Application: Fast Road Camshaft when used in 1300 / 1400 engines.
Unit Type: Blank.
Excellent Mild Road when used in 1600 engines.
Standard springs coil bind, Piper VSSCVH springs must be used.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 4 kg |
|---|---|
| Application | Fast Road |
| Power Band | 1200-6000 |
| Power Increase | 10BHP |
| Duration Inlet | 270° |
| Duration Exhaust | 270° |
| Valve Inlet Lift | .440" 11.17mm |
| Valve Exhaust Lift | .440" 11.17mm |
| Timing Inlet | 25 - 65 |
| Timing Exhaust | 65 - 25 |
| Full Inlet Lift | 110° |
| TDC Inlet Lift | .070" 1.78mm |
| TDC Exhaust Lift | .070" 1.78mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
