SKU: SKU: VXRC2BP270B
Profile: BP270.
Application: Fast Road.
Unit Type: Blank.
Engine Type: B16LES.
Note: uprated valve springs VSSCVXRK are recommended, especially in high-boost applications.
Note: Please check your trigger type. These are to suit the Corsa VXR 1.6 Turbo with ‘E’ type trigger, matching the above engine type. Please use product images for assistance.
Note: For Corsa D VXR 1.6 Turbo with the engine codes Z16LEL, A16LEL, Z16LER, A16LER, A16LES & B16LER, please see VXRCBP270B
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 6 kg |
|---|---|
| Application | Fast Road |
| Power Band | 1800-6500 |
| Duration Inlet | 230° |
| Duration Exhaust | 230° |
| Valve Inlet Lift | .321" 8.15mm |
| Valve Exhaust Lift | .319" 8.10mm |
| Timing Inlet | May-45 |
| Timing Exhaust | 45 - 5 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 110° |
| TDC Inlet Lift | .010" 0.25mm |
| TDC Exhaust Lift | .012" 0.30mm |
| Valve Inlet Clearance | .008" .20mm |
| Valve Exhaust Clearance | .010" .25mm |
