SKU: SKU: P16VGPA
Profile: GPA.
Application: Group A Rally.
Unit Type: Blank.
Note: Not suitable for use with standard O.E springs, Piper VDSMI16 spring kit must be used. Designed for engines utilising Mechanical followers.
Download:-
Right click the link and select 'Save as' to download.
Click the link to open in a new tab.
| Weight | 5 kg |
|---|---|
| Application | Group A |
| Power Band | 2800-7800 |
| Duration Inlet | 282° |
| Duration Exhaust | 282° |
| Valve Inlet Lift | .448" 11.38mm |
| Valve Exhaust Lift | .419" 10.60mm |
| Timing Inlet | 35 - 67 |
| Timing Exhaust | 67 - 35 |
| Full Inlet Lift | 106° |
| Full Exhaust Lift | 106° |
| TDC Inlet Lift | .144" 3.66mm |
| TDC Exhaust Lift | .110" 2.80mm |
| Valve Inlet Clearance | .008" .20mm |
| Valve Exhaust Clearance | .010" .25mm |
