SKU: SKU: P16BP285B
Profile: BP285.
Application: Ultimate Road.
Unit Type: Blank.
Note:Piper supply these camshafts on universal blank castings, meaning they have both the thrust groove & thrust shoulders.
Note: Not recommended for standard injection. Phenomenal power when used with 2 X 45 dcoe's.
Download:-
Right click the link and select 'Save as' to download.
Click the link to open in a new tab.
| Weight | 3 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 2500-7000 |
| Power Increase | 30BHP |
| Duration Inlet | 284° |
| Duration Exhaust | 284° |
| Valve Inlet Lift | .462" 11.73mm |
| Valve Exhaust Lift | .460" 11.68mm |
| Timing Inlet | 36 - 68 |
| Timing Exhaust | 68 - 36 |
| Full Inlet Lift | 106° |
| TDC Inlet Lift | .109" 2.77mm |
| TDC Exhaust Lift | .107" 2.72mm |
| Valve Inlet Clearance | .008" .20mm |
| Valve Exhaust Clearance | .010" .25mm |
