SKU: SKU: MAZKLDEBP285HR
Profile: BP285.
Application: Ultimate Road.
Unit Type: Re-Profiled Camshafts.
Note:These are re-profile camshaft only. You will need to complete our Send Parts form and send us your existing camshafts. For more information, please take a look at our Reprofiling page.
Note: To suit engines utilising hydraulic followers.
| Weight | 10 kg |
|---|---|
| Application | Ultimate Road |
| Duration Inlet | 275° |
| Duration Exhaust | 275° |
| Valve Inlet Lift | .362" 9.20mm |
| Valve Exhaust Lift | .362" 9.20mm |
| Timing Inlet | 29.5 - 65.5 |
| Timing Exhaust | 67.5 - 27.5 |
| Full Inlet Lift | 108° |
| Full Exhaust Lift | 110° |
| TDC Inlet Lift | .053" 1.35mm |
| TDC Exhaust Lift | .049" 1.26mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
