SKU: SKU: FOC16BP320B
Profile: BP320.
Application: Race.
Unit Type: Blank.
Note: For use in 1.6 engines only.
Note: This profile is not recommended for use with standard fuel injection.
Note:Piper VSSFOC16 or VSSFOC16K valve springs must be used.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 4 kg |
|---|---|
| Application | Race |
| Power Band | 3800-8500 |
| Duration Inlet | 288° |
| Duration Exhaust | 284° |
| Valve Inlet Lift | .460" 11.69mm |
| Valve Exhaust Lift | .401" 10.19mm |
| Timing Inlet | 42 - 66 |
| Timing Exhaust | 64 - 40 |
| Full Inlet Lift | 102° |
| Full Exhaust Lift | 104° |
| TDC Inlet Lift | .147" 3.73mm |
| TDC Exhaust Lift | .108" 2.78mm |
| Valve Inlet Clearance | .010" .25mm |
| Valve Exhaust Clearance | .012" .30mm |
