SKU: SKU: FOC16BP285B
Profile: BP285.
Application: Ultimate Road.
Unit Type: Blank.
Note: For use in 1.6 engines only.
Note: This profile is not recommended for use with standard fuel injection.
Note:Piper VSSFOC16 or VSSFOC16K valve springs must be used.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 4 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 3000-7500 |
| Duration Inlet | 272° |
| Duration Exhaust | 240° |
| Valve Inlet Lift | .358" 9.09mm |
| Valve Exhaust Lift | .304" 7.72mm |
| Timing Inlet | 26 - 66 |
| Timing Exhaust | 50 - 10 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 110° |
| TDC Inlet Lift | .055" 1.39mm |
| TDC Exhaust Lift | .018" 0.40mm |
| Valve Inlet Clearance | .008" .20mm |
| Valve Exhaust Clearance | .012" .30mm |
