SKU: SKU: COSBP270HTB
Profile: BP270HT.
Application: Fast Road Turbo.
Unit Type: Blank.
Designed for Turbo engines utilising Hydraulic followers.
Note:When fitting to a 2WD head, Piper COSWASH thrust spacers are required.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new browser.
| Weight | 6 kg |
|---|---|
| Application | Fast Road |
| Power Band | 2000-6200 |
| Power Increase | 20BHP |
| Duration Inlet | 264° |
| Duration Exhaust | 264° |
| Valve Inlet Lift | .340" 8.64mm |
| Valve Exhaust Lift | .340" 8.64mm |
| Timing Inlet | 20 - 64 |
| Timing Exhaust | 64 - 20 |
| Full Inlet Lift | 112° |
| Full Exhaust Lift | 112° |
| TDC Inlet Lift | .034" 0.86mm |
| TDC Exhaust Lift | .034" 0.86mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
