SKU: SKU: ARKBP255HB
Profile: BP255H.
Application: Fast Road.
Unit Type: Blank.
Designed for use in engines utilising Hydraulic followers. See Piper FOLKH
Note:Designed for use in the 1.4L Naturally Aspirated engine or 1.8L Turbo charged engine. Piper PULDK Vernier Pulleys advised.
Note: Not for use in VVC engines.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 4 kg |
|---|---|
| Application | Mild Road |
| Power Band | 2000-7000 |
| Power Increase | 10BHP |
| Duration Inlet | 248° |
| Duration Exhaust | 248° |
| Valve Inlet Lift | .348" 8.84mm |
| Valve Exhaust Lift | .348" 8.84mm |
| Timing Inlet | 14 - 54 |
| Timing Exhaust | 54 - 14 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 110° |
| TDC Inlet Lift | .045" 1.14mm |
| TDC Exhaust Lift | .045" 1.14mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
