SKU: SKU: A16VBP300HB-SHORT
Profile: BP300H.
Application: Rally.
Unit Type: Blank.
Designed for engines utilising Hydraulic followers.
Note: Piper VDSAST16 Valve Springs must be used.
Note: If you require the Exhaust camshaft to be ground on an Inlet blank, please choose ‘YES’ on the drop down box.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 5 kg |
|---|---|
| Application | Rally |
| Power Band | 2600-7800 |
| Duration Inlet | 280° |
| Duration Exhaust | 280° |
| Valve Inlet Lift | .455" 11.56mm |
| Valve Exhaust Lift | .455" 11.56mm |
| Timing Inlet | 34 - 66 |
| Timing Exhaust | 66 - 34 |
| Full Inlet Lift | 106° |
| Full Exhaust Lift | 106° |
| TDC Inlet Lift | .115" 2.92mm |
| TDC Exhaust Lift | .115" 2.92mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
| Short exhaust camshaft required? | YES, NO |
