SKU: SKU: A16VBP285MB-SHORT
Profile: BP285M.
Application: Ultimate Road.
Unit Type: Blank.
Designed for engines utilising Mechanical followers.
Note: Not recommended for use with standard fuel injection.
Note: Piper VDSAST16 Valve Springs must be used.
Note: If you require the Exhaust camshaft to be ground on an Inlet blank, please choose ‘YES’ on the drop down box.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 5 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 2000-7200 |
| Power Increase | 20BHP |
| Duration Inlet | 280° |
| Duration Exhaust | 268° |
| Valve Inlet Lift | .437" 11.10mm |
| Valve Exhaust Lift | .427" 10.85mm |
| Timing Inlet | 34 - 66 |
| Timing Exhaust | 60 - 28 |
| Full Inlet Lift | 106° |
| Full Exhaust Lift | 106° |
| TDC Inlet Lift | .108" 2.74mm |
| TDC Exhaust Lift | .074" 1.88mm |
| Valve Inlet Clearance | .008" .20mm |
| Valve Exhaust Clearance | .010" .25mm |
| Short exhaust camshaft required? | YES, NO |
