SKU: SKU: HKS32018-AT040
HKS LEGAMAX Premium ZN6 (MAIN+CP)
The concept is Best Looking with Power
φ124 large diameter slotted tail design. "Slotted tail" eliminates the lower exhaust resonance. -40% of the stock exhaust pressure loss improves the low-speed torque and engine response.
Uncomfortable sound inside the vehicle’s cabin is reduced, exciting exhaust sound at high speed.Driving can be more comfortable and more fun to drive.
| Cert. No. | JQR20122035 |
|---|
| Vehicle | 86 |
|---|---|
| Model | ZN6 |
| Engine | FA20 |
| Model Year | 12/04 - 21/10 |
| Shape of muffler | SSR (LEGAMAX Premium) | |
|---|---|---|
| Main material | S304 | |
| Diameter of tip | 124 L&R | |
| Diameter of center pipe | 60-54 x 2 (*1) | |
| Close noise level | Stock | 86 |
| HKS | 91 | |
| About road clearance(*2) | Clearance | 125mm |
| Portion of the kit | Center pipe | |
| Remarks | ||
| Product Weight | 17.5kg | |
Main + Center pipe.
*1: About center pipe
Diameter of center pipe is the portion that has the largest diameter. (Excluding silencer and tip.) It is the condition with stock suspension.
*2: Minimum road clearance between HKS muffler (Any parts included in the kit) and road surface. Therefore, it may be different from actual road clearance of the vehicle.
The data is basically the condition with stock suspension. However, please understand that some items have data with low down spring or ride height adjustable suspension kit.
Caution: Hook, bracket, stay may be changed without prior notice.
★ Exhaust noise level at idle.
LEGAMAX Premium
Application
Specifications
86 DBA-, 4BA-ZN6 The concept is Best Looking with Power φ124 large diameter slotted tail design. "Slotted tail" eliminates the lower exhaust resonance. -40% of the stock exhaust pressure loss improves the low-speed torque and engine response. Uncomfortable sound inside the vehicle’s cabin is reduced, exciting exhaust sound at high speed.Driving can be more comfortable and more fun to drive. Cert. No. JQR20122035 Vehicle 86 Model ZN6 Engine FA20 Model Year 12/04 - 21/10 Shape of muffler SSR (LEGAMAX Premium) Main material S304 Diameter of tip 124 L&R Diameter of center pipe 60-54 x 2 (*1) Close noise level Stock 86 HKS 91 About road clearance(*2) Clearance 125mm Portion of the kit Center pipe Remarks Product Weight 17.5kg Remarks Main + Center pipe. About HKS muffler *1: About center pipe Diameter of center pipe is the portion that has the largest diameter. (Excluding silencer and tip.) It is the condition with stock suspension. *2: Minimum road clearance between HKS muffler (Any parts included in the kit) and road surface. Therefore, it may be different from actual road clearance of the vehicle. The data is basically the condition with stock suspension. However, please understand that some items have data with low down spring or ride height adjustable suspension kit. Caution: Hook, bracket, stay may be changed without prior notice. ★ Exhaust noise level at idle. [ CLOSE ]
