This is a factory replacement style, wire-tuck Mil-spec engine harness using high quality tefzel wire and DR-25 loom. Factory layout for the FD3S, but slimmed down of the un-necessary twin turbo sensros.
This is made for a 13b engine, in a Left hand drive RX7 FD3 chassis. Intended for single turbo application only. AUTO Chassis have different engine harness connections.
The harness has connections for:
- Coolant Temp (for the computer)
- Knock Sensor
- Injectors 1-4 -2 leading, 2 trailing
- Ground for the computer
- Oxygen Sensor - Single wire narrow band
- Coolant sender for gauge
- Throttle Position Sensor (TPS)
- Intake Air Temp (IAT)
- 4 transmission connections
- Fan Switch
- Cam & Crank sensors - Trigger 1 and Trigger 2 for the computer sync.
- Oil metering pump
- Boost solenoid
- 2 computer plugs & 2 chassis plugs
- Idle motor (IAC)
This wire harness is made specificly for a RX7 FD3 Chassis, not intended to be used for a 13b standalone engine harness.
For "Right hand drive" customers, the computer type will be for the earlier model
(Our harness does not support the Austrailian 16-bit computer's from 96-98)
Linked is the pinout for this engine harness: chassis customers must send in the large BLUE connector near the computer plugs off of their engine harness for us to install.
