ReadyLift - 3.5" SST Lift Kit - 2017-2022 Ford Super Duty (4WD 1-Piece Driveshaft) - 69-2735

ReadyLIFT 3.5" SST Lift Kit for 2017-2022 Ford Super Duty F-250/F-350 SRW 4WD trucks with a one-piece driveshaft, allowing up to 37" tires.

ReadyLIFT's 69-2735 is a complete 3.5" lift kit for 2017-2022 Ford F-250/F-350 Super Duty SRW 4WD trucks equipped with a one-piece drive shaft. It includes 4" OEM-equivalent tapered rear blocks with integrated bump stop landings, 3.5" coil spring extensions with sound isolators, an OEM-style panhard (track bar) drop bracket, radius arm drop brackets, front shock extensions, and all hardware. The kit allows wheel/tire combinations up to 37" while keeping the smooth OEM ride.

Fits: 2017-2022 Ford Super Duty F-250 / F-350 SRW (single rear wheel) 4WD with a one-piece drive shaft. Not compatible with dual rear wheels or Tremor editions.

Features

• 3.5" front / 1.0" rear lift; maximum tire diameter 37"
• Tapered 4" OEM-equivalent rear blocks with integrated bump stop landings
• 3.5" coil spring extensions with sound isolators
• OEM-style panhard / track bar drop bracket and radius arm drop brackets
• Retains factory front shocks via shock extensions
• Smart Suspension Technology; no cutting or drilling; guaranteed for life

Kit Includes

• Two coil spring spacers with poly sound isolators
• Two front shock extensions
• Radius arm drop brackets
• Two front sway bar mount spacers
• Front track bar relocation bracket
• Two OEM-style tapered rear lift blocks with longer U-bolts and hardware
• Two bump stop extensions
• Extended-length front brake line brackets

Tire Fitment

Recommended 37x12.50 on a 17" or larger, 9" wide wheel with +25 offset / 6" backspacing (minor trimming of the front valance may be necessary).

Notes

Single rear wheel and one-piece driveshaft only (two-piece driveshaft trucks use 69-2736). 2020-2022 trucks may sit slightly taller in the rear. Estimated install time approximately 6 hours.
