ReadyLift - 2.5" SST Lift Kit w/ Radius Arms - 2023-2026 Ford Super Duty Tremor - 69-23251

ReadyLIFT premium 2.5" SST Lift Kit with tubular radius arms for the 2023-2026 Ford Super Duty Tremor F-250/F-350 4WD, clearing 37" tires while keeping rear rake.

The ReadyLIFT 2.5" SST Lift Kit with Radius Arms #69-23251 is the premium version of the Super Duty Tremor kit, clearing 37" tall tires. It adds ReadyLIFT tubular radius arms over the base kit and comes complete with hardware, front coil spring spacers, and OEM-style rear blocks that maintain some rear rake for towing or hauling.

Fits: 2023-2026 Ford Super Duty F-250 / F-350 Tremor models (4WD). Trucks equipped with the Onboard Scale option require the Auto-Leveling Headlight Bypass Bracket Kit (PN 67-23610).

Features

• 2.5" of lift built specifically for Super Duty Tremor models
• Includes ReadyLIFT tubular radius arms
• Front coil spring spacers with rear lift blocks
• Maintains rear rake for towing and hauling
• Allows for 37" tall tires

Kit Includes

• Two coil spring spacers with poly sound isolators
• Two front shock extensions
• Two front sway bar mount spacers
• Two OEM-style rear lift blocks with longer U-bolts and hardware
• Two bump stop extensions
• Extended-length front brake line brackets
• Carrier bearing drop
• Tubular radius arms

Tire Fitment

Recommended 37x12.50 on a 17" or larger, 9" wide wheel with +18 offset / 6" backspacing (minor trimming of the front valance may be necessary).

Notes

Estimated install time approximately 5 hours (excluding alignment and wheel/tire). Onboard Scale trucks require PN 67-23610.
