Manley Spring Retainer, RET-TI 1.500 DOUBLE 7 DEG. - 23677-16

Manley Valve Spring Retainers are engineered using finite element analysis and CNC machined to exacting tolerances to deliver unmatched strength and performance. These retainers reduce valvetrain mass, improve RPM potential, and ensure superior valve control in the most demanding racing applications.

Features

• Made from our high strength Ti-17 Titanium material for maximum strength
• CAD designed for ultimate reduction in mass without sacrificing strength
• Must use 7 degree valve locks

Specs

• Height: +.100 in
• Spring Diameter: 1.500 in
• Valve Stem Diameter: 11/32 in
• Weight: 15.0 grams
• Ti-17 Material (High Strength)
• Made from our high strength TI-17 Titanium Material
• Valve Stem Diameter: 11/32, 3/8
• Product Type: Engine Valve Spring Retainer Set
• Quantity: 16
• Valve Spring Outer Diameter: 1.500
• Valve Spring Retainer Quantity: 16
• Valve Spring Retainer Series: 7 Degree Titanium
• Valve Spring Retainer Material: TI-17 Titanium
• Valve Spring: Manley 221420, 1455, 1456, 1457, 1460, 1461
• Valve Lock Angle: 7
• Height: +.100
• First Step Diameter: 1.325
• Second Step Diameter: 1.035
• Third Step Diameter: 0.705
• Industry: Automotive
• Out of Stock Message: Call for Availability
• Title: Manley Titanium 7 Degree Valve Spring Retainer - Use with Manley Spring 221420, 221455, 221456, 221457, 221460, 221461
