Manley 7 Degree STD 32pc Titanium Retainers for Manley 221419 - 23605-32

Manley Valve Spring Retainers are engineered using finite element analysis and CNC machined to exacting tolerances to deliver unmatched strength and performance. These retainers reduce valvetrain mass, improve RPM potential, and ensure superior valve control in the most demanding racing applications.

Features

• Special 6AL-4V titanium for maximum strength
• CAD designed for ultimate reduction in mass without sacrificing strength
• Must use 7 valve locks
• Use Manley P/N 13098 (recommended) or factory Chevrolet LT valve locks
• Sames as 23625 but +.045" more installed height

Specs

• Height: +.070 in
• Spring Diameter: 1.013 in
• Valve Stem Diameter: 6mm
• Weight: 5.0 grams
• Manley Spring Retainer, RET-TI 1.101 7 DEG 221419
• Product Market: Domestic
• Weight: 5
• Stem Diameter: 6.00
• Valve Stem Diameter: 6.00
• Product Type: Engine Valve Spring Retainer Set
• Quantity: 32
• Valve Spring Outer Diameter: 1.013
• Valve Spring Retainer Quantity: 32
• Valve Spring Retainer Series: 7 Degree Titanium
• Valve Spring Retainer Material: 6AL-4V Titanium
• Valve Spring: Manley 221419
• Valve Lock Angle: 7
• Height: .070
• First Step Diameter: 0.875
• Second Step Diameter: 0.640
• Third Step Diameter: 0.440
• Industry: Automotive
• Out of Stock Message: Call for Availability
• Title: Manley Titanium 7 Degree Valve Spring Retainer Set of 32 - Use with Manley Spring 221419 - Ford Coyote
• Prop 65 Yes/No: Yes
