Mahle MS Piston Set Cummins 4.035in Bore 4.724in Stroke 7.559od 1.575 Pin -47.1cc 16.6 CR Set of 6 - 197952235

Piston (set) - CUMMINS 5.9L B-Series Cast Performance Pistons - 12V — 362cid 4.035 x 2.817CH, 4.724stroke,7.559rod,1.575pin,-47.6cc,1171g,16.5CR, M174+

Application

Cummins 5.9L 12V 362 cu in.

Features & Specs

• Coatings: Grafal
• Clip Style: Snap Ring
• Pin Wall Thickness: 0.413
• UCR Material: Ductile Iron
• UCR Coating: Ceramic Chrome
• Rings Included: Y
• Piston Style: Dish, w/ NO valve reliefs
• Piston Ring Thickness: 3.0mm, 2.4mm, 4.0mm
• Piston Material: Cast, M174+
• Piston Mass: 1171g
• Pins Included: Y
• Pin Style: Floating
• Clips Included: Y
• Pin Material: Steel
• Pin Mass: 575g
• Pin Length: 75.8mm
• Pin Diameter: 40.0mm
• Package Quantity: Sold as a set of 6
• OCR Thickness: 4.0mm
• OCR Tension: Standard
• OCR Material: Chrome plated cast iron
• LCR Thickness: 2.4mm
• LCR Material: Cast Iron
• LCR Coating: Phosphate
• File Fit: N
• Crown Volume: -47.6cc
• UCR Thickness: 3.0mm Keystone

Country of Origin: US  |  Package: Sold as a set of 6
