Mahle MS Piston Set 81.5mm Bore 87.2mm Stroke Stock 138mm Rod 21mm Pin -1cc 10.5 CR Set of 4 - Acura - 929112109

Piston (set) - HONDA / ACURA B16, A1, A2, A3 DOHC VTEC 1.6L — 81.50mm x 30mm CH, 77.4mm stroke,134mm rod,21mm pin,1.0cc,290g,9.5CR, 4032

Application

Honda B16 1.6L

Features & Specs

• Coatings: Phosphate + Grafal
• Clip Style: Round Wire
• Pin Wall Thickness: 0.197
• UCR Material: Stainless Steel
• UCR Coating: Gas Nitrided
• Rings Included: Y
• Piston Style: Dome, w/ 4 valve reliefs
• Piston Ring Thickness: 1.0mm, 1.2mm, 2.8mm
• Piston Material: Forged, 4032
• Piston Mass: 290g
• Pins Included: Y
• Pin Style: Floating
• Clips Included: Y
• Pin Material: Steel
• Pin Mass: 98g
• Pin Length: 50.0mm
• Pin Diameter: 21.0mm
• Package Quantity: Sold as a set of 4
• OCR Thickness: 2.8mm
• OCR Tension: Standard
• OCR Material: Chrome plated stainless steel
• LCR Thickness: 1.2mm
• LCR Material: Cast Iron
• LCR Coating: Phosphate
• File Fit: N
• Crown Volume: 1.0cc
• UCR Thickness: 1.0mm

Country of Origin: US  |  Package: Sold as a set of 4
