Mahle MS Piston Set 04.5-07 Cummins 5.9L Forged Steel Monotherm 4.055 BR 4.724 STK 16.1 CR (6 Qty) - 929969355

Piston (set) - CUMMINS 5.9L B-Series Forged Steel MONOTHERM — 366cid 4.055 x 2.804CH, 4.724stroke,7.559rod,1.575pin,-48.6cc,1736g,16.2CR, Steel

Application

Cummins 5.9L 24V 366 cu in.

Features & Specs

• Coatings: Phosphate + Grafal
• Clip Style: Snap Ring
• Pin Wall Thickness: 0.452
• UCR Material: Ductile Iron
• UCR Coating: Ceramic Chrome
• Rings Included: Y
• Piston Style: Dish, w/ 4 valve reliefs
• Piston Ring Thickness: 3.0mm, 2.4mm, 4.0mm
• Piston Material: Forged, Steel
• Piston Mass: 1736g
• Pins Included: Y
• Pin Style: Floating
• Clips Included: Y
• Pin Material: Steel
• Pin Mass: 430g
• Pin Length: 58.0mm
• Pin Diameter: 40.0mm
• Package Quantity: Sold as a set of 6
• OCR Thickness: 4.0mm
• OCR Tension: Standard
• OCR Material: Chrome plated cast iron
• LCR Thickness: 2.4mm
• LCR Material: Cast Iron
• LCR Coating: Phosphate
• File Fit: N
• Crown Volume: -48.6cc
• UCR Thickness: 3.0mm Keystone

Country of Origin: US  |  Package: Sold as a set of 6
