KC HiLiTES 21-26 Ford Bronco Gravity Titan Overhead Light Bar - AK-91425

At the center of the system is the Gravity Titan LED Light Bar, KC's most advanced lighting platform. Powered by the Titan Core and 3-Source LED optics, Titan produces a larger illumination zone, increased peak intensity, and greater beam distance than previous Gravity platforms. Dual Power Modes allow you to switch between full High Power Mode for nighttime driving and an integrated Amber Dust Light that acts as a highly visible marker in dusty, snowy, or low-visibility conditions. The system is completed with Ford Bronco overhead mounting brackets built from heavy-duty steel and finished in a black powder coat. Designed specifically for the Bronco's factory accessory mounting locations, these brackets provide a secure mounting solution engineered to withstand the demands of off-road use.

Features

• FEATURES
• 8x Gravity 6" Light Covers – Black with Yellow KC Logo
• 1x Complete Wiring Kit with 3-Position Switch
• 1x Cover Removal Tool
• 1x Pair of Ford Bronco overhead mounting brackets (SKU 7332)
• Fitment & Installation Notes
• Vehicle Fitment: 2021-2026 Ford Bronco
• Mounting Location: Overhead/windshield
• Installation: Bolt-on installation using factory mounting locations
• Compatible with factory hardtops and soft tops
• Dual Power Modes: Amber LED Dust Light: Highly visible marker for low-visibility conditions
• High-Power Mode: Intense forward-facing illumination for nighttime trail use
• Titan Core: Patented Pass-Through Front Cooling: Superior thermal management
• 3-Source LED Optics: Delivers comprehensive mid- and long-range lighting coverage
• Linkable and Curvable: Patented Infinity Ring system offers expandable widths and the option to curve or straighten your setup
• Gravity Reflective Diode Technology: Ensures unmatched beam precision and efficiency, providing brighter and more focused light
• MoistureBlock Technology: Integrated weather-sealed plug protects against water intrusion
• WHAT'S INCLUDED: 1x Gravity Titan 50" LED Light Bar 8-Light Combo Beam (SKU 91418)

Specifications

• Total Wattage: 89.6W (Amber) /315.84W (White)
• Lux Total: 10,205 lx
• Lux: 1,443lx (Spot) / 775lx (Wide 40)
• Lumens Total: 23,776 lm
• Lumens Per Light: 2,972 lm
• Light Size (Inch): 50.0 in
• Amp Draw Total: 7.47 A (Amber) / 26.32 A (White)
• Light Temp - Units: Kelvin
• Light Temp (Kelvin): 5000 K
• Lens Color: Clear
• LED Color: Amber & White
• IP Rating: IP68
• Includes Installation Hardware: Yes
• Color: Black
• Candela Total: 1,020,500 cd
• Candela: 144,250cd (Spot) / 77,500cd (Wide 40)
• Beam Pattern: Combo
• Beam Distance (Meters): 1,010 m
• Voltage: 9V-36V
• Light Technology: LED
• Amp Draw Per Light: 0.93 A (Amber) / 3.29 A (White)

Application

2018-2024 Jeep Wrangler JL/Gladiator JT
