ICON Part # ICO56523

ICON 2025 Toyota 4Runner 0-3in Rear 2.0 VS Aluminum Series Internal Reservoir Shock - 56523

$273.91 CAD
Earn 273 Dino Dollars on this order. How it works

Before you order

Customers also viewed

Canadian since 2005 Questions? Email sales@raptorracing.com

ICON Vehicle Specific (V.S.) 2.0 Aluminum Series shock absorbers are the ultimate in cost effective upgrades, specifically tailored by ICON engineers for your application. The V.S. 2.0 Aluminum Series shocks are a high-quality upgrade for the everyday street driver and weekend warrior looking for improved on and off-road performance. Like all ICON shock absorbers, V.S. 2.0 Aluminum Series shocks are fully rebuildable and re-tunable. For those using their vehicle in extreme off-road situations, consider the ICON V.S. 2.5 Aluminum Series shock to handle extra abuse and punishment your suspension will need to endure.

Installation Instructions

  • Nitrogen charged monotube design with internal reservoir
  • One piece linear/digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
  • 5/8” chrome plated hardened steel shaft resists corrosion and pits
  • 6061 aluminum rod end, top cap, and internals ensure strength and durability
  • Polyurethane bushings, zinc plated sleeves, and forged steel mounting stems for OE factory type fitment
  • 6063 anodized aluminum body and reservoir tubing for superb heat dissipation, excellent corrosion resistance, and high-tech appearance
  • Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
  • Nitrile rubber top out bumper for noise free operation
  • Rubber dust boot included for added shaft protection

  • Boot Color: Black
  • Body Color: Gray
  • Body Diameter: 2 in.
  • Bore Diameter: 1.75 in.
  • Bushing Color: Black
  • Bushing Included: yes
  • Bushing Material: Polyurethane
  • Compressed Length: 16.1 in.
  • Cylinder Color: Gray
  • Cylinder Finish: Anodized
  • Damping Type: Oil
  • Dust Shield Included: Yes
  • Dust Shield Material: Rubber
  • Extended Length: 26.5 in.
  • Finish: Anodized
  • Gas Charged: Yes
  • Internal Construction Type: Single Tube
  • Internal Rebound Bumper: Yes
  • Lower Mount Bushing Inside Diameter: .75 in.
  • Lower Mount Bushing Overall Length: 1.825 in.
  • Lower Mount Type: Eyelet
  • Maximum Ride Height Raising Distance: 3 in.
  • Shock Absorber Body End Measuring Point: Shoulder of Stem
  • Shock Absorber Rod End Measuring Point: Center of Eyelet
  • Shock Stroke: 10.4 in.
  • Travel Length: 10.4 in.
  • Type: Telescopic
  • Upper Mount Stem Overall Length: 2.5 in.
  • Upper Mount Stem Thread Size: M12 - 1.25
  • Upper Mount Type: Stem
  • Valving Type: Digressive
  • Reservoir Type: Internal
  • Rod Diameter: .625 in.
  • Shaft Diameter: 0.625 in.
  • Shaft Material: Chrome
