ICON Part # ICOK67104

ICON 05-07 Ford F250/F350 7in Stage 5 Suspension System - K67104

Earn 12,425 Dino Dollars on this order. How it works

Before you order

Customers also viewed

Canadian since 2005 Questions? Email sales@raptorracing.com

The Stage 5 system sees the inclusion of the ICON Vehicle Dynamics Ford Super Duty 4-Link kit, which further improves performance by eliminating suspension bind commonly experienced with factory radius arms during articulation. This “freeing up” of the front end and the ability of the 4-Link Kit to maintain positive caster through the range of travel equates to an unparalleled ride quality in all conditions. With the endless hours ICON has spent testing and tuning our suspension components and shocks as a complete package, you can rest assured knowing that you have the best suspension solution on the market.

Installation Instructions
Installation Instructions
Installation Instructions
Installation Instructions
Installation Instructions

  • Approximately 50% increased front wheel travel over stock
  • One-piece impact extruded aluminum cylinders offer excellent corrosion resistance and consistent finish
  • FK Rod End bearings provide extended longevity and minimal deflection
  • ICON-engineered dual rate coil springs deliver exceptional vehicle control over varying terrain
  • Progressive leaf springs improve ride quality without reducing towing capacity
  • ICON 4-Link system eliminates binding during articulation and maintains positive caster through the entire range of travel
  • ICON CDC Valve allows for 10 clicks of quick and easy compression adjustability
  • ICON shocks feature vehicle specific tune for superior performance and ride quality
  • Shocks are fully rebuildable and re-valvable

  • Maximum Lift Height Rear: 5 in.
  • Front Spring Rate: 600 lb/in
  • Maximum Lift Height Front: 7 in.
  • Leaf Spring Color: Black
  • Spring Color: Black
  • Coil Spring Color: Black
  • Leaf Spring Bracket Color: Black
  • Coil Spring End 1 Type: Closed
  • Coil Spring End 2 Type: Closed
  • Damping Adjustment Type: Manual
  • Recommended Aftermarket Tires: 37" x 12.50" (Larger tires may fit but fender trimming and modifications will be required.)
  • Rear Shock Body Diameter: 2.5 in.
  • Coils Quantity Front: 2
  • Leaf Spring Leaf Quantity: 10
  • Coil Spring Material: Steel
  • Bushing(s) Included: Yes
  • Mounting Hardware Included: Yes
  • Shocks Included: Yes
  • Adjustable Compression: Yes
  • Adjustable Damping: Yes
  • Dual Rate Coil Springs: Yes
  • OEM Wheels & Tires Fitment: Yes
  • Front Reservoir Style: Piggyback
  • Rear Reservoir Style: Piggyback
  • Front Spring Rate Type: Progressive Dual Rate
  • Leaf Spring Material: Steel
