SKU: SKU: FOX981-20-005
FOX devotes countless hours of research and development to design race-winning suspension that withstands incredible punishment and provides consistent performance you can rely on. Regardless of whether you are flying high over the desert or struggling to stick to a rock face on an off-camber climb, our shocks will give you the damping performance, suspension control and proper spring rate to get the job done.
Rebuildable and serviceable. Custom valving options available.
Our new 2.0 Performance Elite Series Smooth Body shocks are available in 5/8” or 7/8” hard chrome plated 4130 chromoly shaft variations. Dual Speed Compression (DSC) adjusters are also available on shocks equipped with 7/8” shafts.
| Series | Performance Elite |
| Body Diameter (in) | 2 |
| Body Material | Steel |
| Bottom Mount | Eyelet |
| Top Mount | Eyelet |
| Compressed Length (in) | 17.13 IN |
| Extended Length (in) | 28.22 IN |
| Mounting | 1/2 x 1-1/4 |
| Reservoir Dimensions | 2.17 x 11.00 |
| Reservoir Type | Remote |
| Shaft Size (in) | 5/8 IN |
| Travel (in) | 11.09 IN |
| Type | Smooth Body |
| Eyelet Length (in) | 1.68 IN |
| Valving | 807-24-006 |
| Seal Kit | 803-04-034 |
| Hose | -5 x 12.00 |
| Body Finish | Clear Zinc Plated |
| Travel (rounded) | 11 |
