Eagle Replacement Rod Bolts ARP8740 7/16in Thread 1.40in UHL - Single - EAG12005-1

Eagle rod bolts are manufactured by ARP to Eagle's specifications. These are not off-the-shelf ARP bolts. Always use Eagle's bolts with Eagle rods.

Specifications

• ARP 8740 - 190kpsi tensile strength, 180kpsi yield strength
• 7/16" thread
• 1.4" under-head length
• 7/16" 12pt socket size
• Stretch to .0044"-.0046"
• Use either torque method or stretch method - DO NOT use both!
