Bilstein B6 2012 Ford F-350 Super Duty XLT 4WD Ext. Cab Front 46mm Monotube Shock Absorber - 24-186681

Bilstein B8 5100 shock absorbers are designed as a direct fit solution for lifted trucks and SUV’s. These shock absorbers feature a monotube design which provides consistent fade free performance. B8 5100 shock absorbers utilize a unique, velocity sensitive, digressive piston which reacts to changing road conditions. All B8 5100 shock absorbers are tuned for each specific application to assure optimal performance is achieved. B8 5100 shock absorbers offer a significant improvement in ride quality, handling, and comfort.

Features

• 46mm monotube design ensures consistent, fade-free performance in all conditions
• Patented digressive valving instantly reacts to changing surface conditions
• Vehicle specific tuning

Specifications

• Upper Mount Type: Stem
• Internal Design: Monotube
• Extended Length (mm): 676.0
• Extended Length (in): 26.61
• Lower Mount Type: Eye 14.4mm
• Series: B8 5100
• Adjustable Damping: Non-Adjustable
• Spring Seat Included: No
• Piston Diameter: 46mm
• Stroke/Travel Length (in): 10.28
• Shaft Diameter: 14mm
• Stroke/Travel Length (mm): 261.1
• Body Design: Smooth Body (Non-Coilover)
• Finish: Zinc Plated
• Collapsed Length (mm): 414.8
• Boot Included: Black Bellows
• Reservoir: No
• Collapsed Length (in): 16.33

Application

• Ford F-250 Super Duty 2005-2016, F-350 Super Duty 2005-2016
