Bilstein 23-26 Chevrolet Colorado B8 5100 (Ride Height Adjustable) Shock Absorber - Front - 24-336345

Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.

Features

• 46mm monotube design ensures consistent, fade-free performance in all conditions
• Practical alternative to coil spring spacers, with the benefit of Bilstein monotube technology
• Adjustable spring seat offers 0-2.75in of lift, depending on the application

Specifications

• Stroke/Travel Length (mm): 125.5
• Collapsed Length (in): 15.96
• Shaft Diameter: 18mm
• Extended Length (in): 20.91
• Stroke/Travel Length (in): 4.95
• Collapsed Length (mm): 405.5
• Piston Diameter: 46mm
• Extended Length (mm): 531.0
• Series: B8 5100 (Ride Height Adjustable)
• Lower Mount Type: Crossbar
• Internal Design: Monotube
• Boot Included: No
• Reservoir: No
• Adjustable Damping: Non-Adjustable
• Body Design: Smooth Body (Non-coilover)
• Upper Mount Type: Stem
• Spring Seat Included: Yes
• Finish: Zinc Plated

Application

• Chevrolet Colorado 2023-2026
