Bilstein 2024+ Ford Ranger B8 5100 Rear Shock - 0-1.in Rear Lift - 24-336222

Bilstein B8 5100 shock absorbers are designed as a direct fit solution for lifted trucks and SUV’s. These shock absorbers feature a monotube design which provides consistent fade free performance. B8 5100 shock absorbers utilize a unique, velocity sensitive, digressive piston which reacts to changing road conditions. All B8 5100 shock absorbers are tuned for each specific application to assure optimal performance is achieved. B8 5100 shock absorbers offer a significant improvement in ride quality, handling, and comfort.

Features

• 46mm monotube design ensures consistent, fade-free performance in all conditions
• Patented digressive valving instantly reacts to changing surface conditions
• Vehicle specific tuning

Specifications

• Shaft Diameter: 14mm
• Collapsed Length (in): 16.22
• Stroke/Travel Length (mm): 223.0
• Extended Length (in): 25.00
• Collapsed Length (mm): 411.9
• Piston Diameter: 46mm
• Extended Length (mm): 634.9
• Stroke/Travel Length (in): 8.78
• Series: B8 5100
• Boot Included: Black Bellows
• Lower Mount Type: Eye 12.1mm
• Upper Mount Type: Eye 12.1mm
• Internal Design: Monotube
• Reservoir: No
• Spring Seat Included: No
• Adjustable Damping: Non-Adjustable
• Body Design: Smooth Body (Non-coilover)
• Finish: Zinc Plated

Application

• Ford Ranger 2024-2026
