Bilstein B8 5160 remote reservoir shock absorbers are designed as a direct fit solution for lifted trucks and SUVs. The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application.
Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting and an attractive billet reservoir mount where applicable providing a clean, low profile installation. B8 5160 remote reservoir shock absorbers will increase overall durability of your vehicle allowing you to conquer the harshest of off-road environments.
46mm monotube design ensures consistent, fade-free performance in all conditions.
Self-adjusting deflective disc valving reacts immediately to surface changes enabling maximum vehicle control.
Remote reservoir increases shock oil capacity for greater heat dissipation.
| Collapsed length (in) | 15.91 |
|---|---|
| Extended length (in) | 27.49 |
| Extended length (mm) | 698.2 |
| Series | B8 5160 |
| Lower mount type | Eye 12.1mm |
| Internal design | Monotube |
| Boot included | No |
| Spring seat included | No |
| Adjustable damping | Non-Adjustable |
| Body design | Smooth Body (Non-Coilover) |
| Upper mount type | Stem |
| Billet reservoir clamp included | Yes |
| Reservoir | Yes |
| Finish | Zinc Plated |
| Piston diameter | 46mm |
| Collapsed length (mm) | 404.0 |
| Stroke/travel length (in) | 11.58 |
| Shaft diameter | 14mm |
| Stroke/travel length (mm) | 294.1 |
| Part number | 25-311990 |
