SKU: SKU: VXRBP270HB
Profile: BP270.
Application: Fast Road.
Unit Type: Blank.
Note: This profile is only available on Blank castings. Milder profile is available on Re-Profiled Camshafts, please contact Piper Sales for details.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 6 kg |
|---|---|
| Application | Fast Road |
| Power Band | 1500-6700 |
| Power Increase | 15BHP |
| Duration Inlet | 254° |
| Duration Exhaust | 254° |
| Valve Inlet Lift | .400" 10.16mm |
| Valve Exhaust Lift | .400" 10.16mm |
| Timing Inlet | 17 - 57 |
| Timing Exhaust | 57 - 17 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 110° |
| TDC Inlet Lift | .035" 0.89mm |
| TDC Exhaust Lift | .035" 0.89mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
