SKU: SKU: V8TMAX
Profile: TMAX.
Application: Off Road / Towing.
Unit Type: Blank.
Rocker Ratio 1.60:1.
Download:-
Note: Great for bottom end torque and power, perfect for towing and off road applications such as green laning.
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 3 kg |
|---|---|
| Application | Off Road/Towing |
| Duration Inlet | 264° |
| Duration Exhaust | 264° |
| Valve Inlet Lift | .416" 10.57mm |
| Valve Exhaust Lift | .416" 10.57mm |
| Timing Inlet | 26 - 58 |
| Timing Exhaust | 64 - 20 |
| Full Inlet Lift | 106° |
| Full Exhaust Lift | 112° |
| TDC Inlet Lift | .049" 1.24mm |
| TDC Exhaust Lift | .036" 0.92mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
