SKU: SKU: SUBBP285H
Profile: BP285H.
Application: Ultimate Road.
Unit Type: Blank.
Note:Versions 4 - 10 available. To avoid delay in your order, please state which version type you require in the order notes at checkout.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 7 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 2500-7000 |
| Duration Inlet | 264° |
| Duration Exhaust | 264° |
| Valve Inlet Lift | .400" 10.13mm |
| Valve Exhaust Lift | .400" 10.13mm |
| Timing Inlet | 22 - 62 |
| Timing Exhaust | 62 - 22 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 110° |
| TDC Inlet Lift | .056" 1.43mm |
| TDC Exhaust Lift | .057" 1.44mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
