SKU: SKU: SIGVCTBP285B
Profile: BP285.
Application: Ultimate Road.
Unit Type: Blank.
Note:Additional machining to the tappet bore is required with this profile to allow the camshafts to rotate.
Note: Uprated Valve Springs VSSFOC16K Required.
Note:ECU Must Be Remapped with this profile.
Note: Performance exhaust recommended for best results.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 4 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 2000-7200 |
| Duration Inlet | 268° |
| Duration Exhaust | 256° |
| Valve Inlet Lift | .386" 9.80mm |
| Valve Exhaust Lift | .370" 9.40mm |
| Timing Inlet | Jun-94 |
| Timing Exhaust | 69 - 07 |
| Full Inlet Lift | 140° |
| Full Exhaust Lift | 121° |
| TDC Inlet Lift | .003" 0.08mm |
| TDC Exhaust Lift | .012" 0.30mm |
| Valve Inlet Clearance | .008" .20mm |
| Valve Exhaust Clearance | .010" .25mm |
