SKU: SKU: SAX16BP270HB
Profile: BP270H.
Application: Fast Road.
Unit Type: Blank.
Note: For use in engines utilising Hydraulic followers. You must use VSSVTSK with these camshafts.
Note:Over 150 bhp achievable when used with after market air filter, exhaust and a flowed cylinder head.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 3 kg |
|---|---|
| Application | Fast Road |
| Power Band | 2000-7000 |
| Power Increase | 15BHP |
| Duration Inlet | 260° |
| Duration Exhaust | 260° |
| Valve Inlet Lift | .380" 9.65mm |
| Valve Exhaust Lift | .380" 9.65mm |
| Timing Inlet | 20 - 60 |
| Timing Exhaust | 60 - 20 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 110° |
| TDC Inlet Lift | .035" 0.90mm |
| TDC Exhaust Lift | 035" 0.90mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
