SKU: SKU: R172BP285B
Profile: BP285.
Application: Ultimate Road.
Unit Type: Blank.
Note:These camshafts are supplied with the following genuine Renault parts. #8200778847 Pulley Stud with pre applied thread locking compound. #8200793248 Pulley Nut.
Note: Supplied with shims.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 5 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 2200-7500 |
| Power Increase | 20BHP |
| Duration Inlet | 276° |
| Duration Exhaust | 268° |
| Valve Inlet Lift | .420" 10.67mm |
| Valve Exhaust Lift | .393" 9.98mm |
| Timing Inlet | 28 - 68 |
| Timing Exhaust | 60 - 28 |
| Full Inlet Lift | 110° |
| Full Exhaust Lift | 106° |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
