SKU: SKU: R16VBP285HB
Profile: BP285H.
Application: Ultimate Road.
Unit Type: Blank.
Designed to be used in engines utilising Hydraulic followers.
Note: Piper PULDCLIO Vernier Pulleys recommended.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 5 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 2500-7300 |
| Power Increase | 18BHP |
| Duration Inlet | 268° |
| Duration Exhaust | 268° |
| Valve Inlet Lift | .438" 11.13mm |
| Valve Exhaust Lift | .438" 11.13mm |
| Timing Inlet | 28 - 60 |
| Timing Exhaust | 60 - 28 |
| Full Inlet Lift | 106° |
| Full Exhaust Lift | 106° |
| TDC Inlet Lift | .087" 2.21mm |
| TDC Exhaust Lift | .087" 2.21mm |
| Valve Inlet Clearance | HYDRAULIC |
| Valve Exhaust Clearance | HYDRAULIC |
