SKU: SKU: PUMBP285B
Profile: BP285.
Application: Ultimate Road.
Unit Type: Blank.
Note:This profile is not recommended for use with standard fuel injection.
Download:-
Right click the link and select 'Save link as' to download.
Click the link to open in a new tab.
| Weight | 4 kg |
|---|---|
| Application | Ultimate Road |
| Power Band | 3500-8200 |
| Duration Inlet | 280° |
| Duration Exhaust | 272° |
| Valve Inlet Lift | .368" 9.35mm |
| Valve Exhaust Lift | .358" 9.09mm |
| Timing Inlet | 34 - 66 |
| Timing Exhaust | 64 - 28 |
| Full Inlet Lift | 106° |
| Full Exhaust Lift | 108° |
| TDC Inlet Lift | .105" 2.67mm |
| TDC Exhaust Lift | .061" 1.56mm |
| Valve Inlet Clearance | .010" .25mm |
| Valve Exhaust Clearance | .010" .25mm |
